Logitrans ELF1001, Semi Electric Stacker Truck, Wrapover Forks, 1000kg / 1200kg

For the ultimate multi-tasker, look no further than the Logiflex from Danish manufacturer Logitrans. Available in manual, semi-electric and fully powered versions, with one truck you can lift a pallet, transport a reel and move a heavy machine. High flexibility and efficiency - this stacker can transport, lift and handle many types of goods.

The standard ELF has an adjustable fork span from 350mm to 560mm*. Other adjustable spans are also available (350-800mm / 350-920mm / 560-1056mm). Extra short and extra long fork lengths and support leg lengths are available (600mm, 800mm or 1520mm).

Built to excellent European standards, all Logitrans equipment is backed up with a 2 year parts warranty.

Customise your ELF: bespoke fork sizes and fork types are available for handling non standard pallets, box pallets, crates, stillages, dolavs and IBCs. On models with an adjustable fork carriage, the forks can be easily detached and replaced with other attachments (eg boom spear, crane arm) for multi-tasking. Personalise your stacker by having it painted in your company colour. Please contact us to discuss your requirements.

With wrapover support legs, this pallet stacker is designed to handle open pallets, via sides where bottom runners are not present. If your are lifting closed UK Chep pallets (with bottom runners), then a straddle stacker will be required. The ELF is perfect for shops, offices, retail, manufacturing and warehouse operations, and in packing and production areas: allowing many different tasks to be performed with one machine.

As an option, stainless steel forks are available for applications where higher hygiene or corrosion resistance is required on surfaces in direct contact with goods being handled. A fully stainless steel version is also available for high care areas in food production, chemical and pharmaceutical applications.

For busy packing applications, remote control is available, while Level Control saves even more time by automatically adjusting the pallet to the correct working height, as it is packed or unpacked. For fragile, or expensive goods that require careful handling, an optional slow lowering valve prevents goods from being damaged by sudden stops when lifting & lowering (see video).

Logitrans put their focus on the safety and ergonomic working conditions of the user. The ELF has a transparent, impact resistant safety screen, giving the operator optimum view conditions. No damage to surroundings, pallets and goods – Logiflex has an elegant design with rounded corners.

Features:

• Electric lift to save time
• Wrapover forks with adjustable fork span*, for handling open pallets (via sides without bottom boards)
• Adjustable forks can be easily detached and replaced with other attachments (eg crane arm, boom spear) for multi-tasking
• Powered drive and 1200kg capacity are also available
• Compact construction and tight turning angle: perfect for confined areas
• Transparent safety screeen, for optimum operator view
• Optional: short and long fork lengths and support leg lengths (600mm, 800mm or 1520mm**) are available
• Lift heights from 920mm to 3270mm***
• Optional: wired or wireless remote control
• Optional: level control - the height of the pallet is automatically adjusted to optimum working height, as it is loaded/unloaded
• Optional: stainless steel forks available on models with an adjustable fork carriage
• A straddle version is available for handling closed pallets with bottom runners
• This model can be customised with bespoke fork widths & fork lengths, to handle many different pallet types.
• This model can be customised with other bespoke attachments (eg boom spear, crane arm) to suit your specific requirements
• 2 year warranty

* Lowered height 85mm/90mm at fork span 560mm and 145mm at all other fork spans.

** Reduced capacity 750kg

*** Lift heights above 2500mm have restricted load capacity: see load diagram
